Bottom lock box dieline


Building a bottom lock box dieline allows you to perfectly fit your product and reduce the assembly time. Many easy-to-use features let you create the dieline in a minute!

Bottom lock box dieline

Building a bottom lock box dieline allows you to perfectly fit your product and reduce the assembly time. Many easy-to-use features let you create the dieline in a minute!

Trusted by leading companies


Designing a bottom lock box dieline is effortless!

A bottom lock box is a folding carton with an interlocking pre-glued base that assembles quickly without adhesive, providing a sturdy, secure bottom ideal for medium-to-heavy packaging, often and cost-effectively. Discover Pacdora's extensive bottom-lock box template library, perfect for any project. Easily adjust dimensions, material, and thickness in Pacdora's dieline generator, then export your dieline in PDF, DXF, JPG, or AI format.

Features of a bottom lock box


Definition

A bottom lock box, or crash lock bottom box, is a pre-glued packaging design whose base snaps securely into place for fast assembly, delivering enhanced strength and dependable support for heavier or fragile, delicate products.


Dimensions

The dimensions of bottom lock boxes vary according to their shapes and purposes. Boxes holding bowls are different from those holding candles. Designers should measure the sizes of their products before creating the boxes.


Applications

A bottom lock box suits retail packaging, cosmetics, food, electronics, gifts, subscription kits, and e-commerce orders, providing sturdy protection, quick assembly, efficient packing, and reliable support for heavier or fragile goods.

How to create a bottom lock box dieline?

How to create a bottom lock box dieline?

Merits of using a bottom lock box dieline

1. Exact alignment

Dielines ensure panels and flaps align perfectly, guaranteeing sturdy bases, preventing misfolds, and protecting products during handling, transit, and storage.

2. Easy assembly

Pre-scored creases and panel alignment simplify folding and locking, enabling quick, tool-free assembly that reduces labor time and speeds workflows.

3. Brand accuracy

Precise dieline guides position artwork, logos, and finishes accurately, ensuring consistent print registration and impactful branding across every packaging piece.
